Temperature and Humidity Sensor for Interior Air Purification System

The core of the air purification system in the vehicle is the air purifier. The air purifier, also known as "air cleaner", air purifier and purifier, refers to products that can absorb, decompose or transform various air pollutants (generally including decoration pollution such as PM2.5, dust, pollen, peculiar smell and formaldehyde, bacteria and allergens), and effectively improve air cleanliness, The main application fields are household, commercial, automobile, industry, building, etc.There are many different technologies and media in the air purifier, so that it can provide users with clean and safe air. Common air purification technologies include: adsorption technology, negative (positive) ion technology, catalysis technology, photocatalyst technology, super structured light mineralization technology, HEPA high-efficiency filtration technology, electrostatic dust collection technology, etc; Material technology mainly includes photocatalyst, activated carbon, synthetic fiber, HEPA efficient material, anion generator, etc. The existing air purifiers are mostly composite, that is, a variety of purification technologies and material media are adopted at the same time.Step 1: its working principle is to monitor the air quality and smell in the vehicle in real time through a sensor. When the system thinks that the air pollution in the vehicle exceeds the standard, the system will first command the air conditioning system to use external circulation to inhale fresh air. After inhalation, the fresh air will pass through a filter element made of grape seed polyphenols to filter pollen, odor and some allergens.

Step 2: the humidity sensor inside the interior rearview mirror adjusts the dehumidification mode of the air conditioner by detecting the fog of the window to avoid excessive drying of the air. This function can only monitor the humidity and adjust the dehumidification mode of the air conditioner, and does not have the humidification function.Step 3: the filtered fresh air comes to the lower part of the central console through the air duct. There is a fragrance device equipped with green leaf ethanol and fragrant wood spices, which will melt the natural fragrance of some trees and green leaves into the air.Step 4: when the air reaches the air outlet of the air conditioner, the negative ion generator produces a large number of negative ions and mixes them into the air. Finally, the system simulates the natural wind flow mode and frequency according to the sunlight exposure and the outside temperature, and blows the air into the cabin to create a comfortable feeling of walking through the forest.

In addition, if the system detects that the external air is bad, it will automatically switch to internal circulation mode like other intelligent automatic air conditioners. However, after switching, the air conditioning filter element and negative oxygen ion generator can still filter and purify the air in the vehicle, which is also a major feature. The purpose of this system is to free the driver and passenger from excessive tension through the flowing wind and aromatic air, keep a clear mind and enter a relaxed state with high attention and concentration.

Finally, a temperature and humidity sensor that can be used in the vehicle air purification system is recommended. The high-quality temperature and humidity sensor imported by industrial mining network from abroad is the digital temperature and humidity sensor - htu21d. Htu21d is a plug and play humidity and temperature composite sensor, which is an ideal choice for OEM applications that need reliable and accurate measurement. It is a series of modular products designed for transportation applications. It adopts DFN package suitable for reflow soldering, and the size is only 3 x 3 x 1mm; Provide corrected, linear I C digital output signal. The temperature sensing element of the sensor can effectively measure gas, liquid or solid. In addition, the sensor can detect low power, and the checksum is used to improve communication reliability. All this benefits from its high-performance sensitivity, measurement accuracy and stability. At the same time, the easy installation thread structure provides reliability in harsh environments. The numerous mechanical and electronic interfaces of htu21d temperature and humidity sensor simplify the installation, which can not only meet the specific application needs of different customers, but also be easily compatible with most existing applications.
